Brother BAS-370H-05A 700mm x 700mm Programmable Pattern Auto Eject Industrial Sewing Machine

Brother BAS-370H-05A
Bridge Type Programmable Electronic Pattern Sewing Machine (700mm x 700mm)

The Brother BAS-370H-05A features a spacious sewing area of 700mm x 700mm, ideal for accommodating multiple workpieces like shoes or bags simultaneously, as well as larger applications such as automotive airbags, significantly enhancing productivity.

Key Features:

• High-Performance Bridge Mechanism: With an independent X and Y feed mechanism, this machine ensures superior sewing quality at impressive speeds, reaching up to 2,500 stitches per minute. A built-in needle cooler helps prevent thread breakage, allowing for consistent performance even at maximum speed.

• Advanced Digital Tension and Thread Breakage Detection: The innovative digital tension system allows for the use of various thread sizes by expanding the upper thread tension range. The machine quickly detects needle thread breakage, minimizing defects in your workpieces.

• Machine Head Lifting Function: The machine head can lift up to 70mm, accommodating thicker materials and clamps, thus allowing for a broader range of applications without interference.

• Simplified Access to Shuttle Hook Area: The magnetic auxiliary plate enables quick removal without tools, simplifying adjustments near the shuttle area for efficient maintenance.

• Compact Design for Effective Space Utilization: The BAS-370H-05A has a small footprint compared to traditional models, freeing up valuable factory floor space while providing a larger sewing area.

Technical Specifications:

• Model: Brother BAS-370H-05A
• Stitch Form: Single needle lock stitch
• Max. Sewing Speed: 2,500 sti/min
• Max. Sewing Area: 700mm x 700mm
• Footprint: 1,699mm x 2,076mm
• Feed Mechanism: Intermittent feed (pulse motor drive)
• Stitch Length: 0.05-20.0mm (adjustable in 0.05mm increments)
• Max. Stitches Per Program: 100,000
• Max. Programs: 999
• Work Clamp Lift Amount: Max. 52.5mm
• Stepping Presser Foot Stroke: 0-10mm (in 0.1mm increments)
• Hook Type: Double-capacity shuttle hook
• Head Lifting Function: Standard
• Needle Cooler, Thread Wiper, Thread Trimmer: Standard
• Digital Tension and Thread Breakage Detector: Standard
• Data Storage: Internal flash memory (expandable)
• Motor: AC servo motor 550W
• Weight: Approx. 810kg
• Power Supply: Single phase 220V/230V; 3-phase 200V/220V/380V/400V
• Power Consumption: 1200VA / 700Wh
• Air Pressure Consumption: 0.5MPa; Needle cooler ON: 1.8l/min, OFF: 0.2l/min
