GROZ BECKERT 135X17 SAN 5 GEBEDUR SIZE 140/22 INDUSTRIAL SEWING MACHINE NEEDLES

Groz Beckert 135x17 SAN 5 GEBEDUR Size 140 / NM 140 / Size 22 Industrial Sewing Machine Needles – Pack of 10
Point Type: RG (Normal round point with small ball)
Compatible Systems: 135x17 SAN 5, VERSION 5.2, 37:20

Engineered for extreme sewing environments, the Groz Beckert 135x17 SAN™ 5 GEBEDUR Size 140 (NM 140 / Size 22) needles are designed to tackle heavy technical textiles and complex material blends with ease. These industrial-grade needles feature GEBEDUR™ titanium nitride coating, boosting surface hardness and extending durability in the most stress-prone zones — especially the needle point and eye.

The SAN™ 5.2 geometry includes a reinforced blade for improved stability, a widened eye for thicker threads, and double point grooves for advanced thread guidance in multi-directional sewing. The RG point (slightly rounded with small ball) makes this needle ideal for both delicate and durable materials, from knits and microfibers to airbags, canvas, nets, seat belts, and coated textiles.

Key Features:

• Titanium GEBEDUR™ Coating – Provides superior protection against wear, extending needle life and improving performance in industrial environments.

• SAN™ 5.2 Needle Design – Reinforced blade, scarf chamfers, and twin point grooves for optimal performance on technical and coated fabrics.

• RG Point (Rounded with Small Ball) – Excellent for button sewing, embroidery, chainstitch, and sewing on knits, microfiber, and synthetic blends.

• Optimised for Multi-Directional Stitching – Supports advanced production techniques and high-tension sewing.

Technical Specifications:

• Needle System: 135x17 SAN 5 / VERSION 5.2 / 37:20

• Needle Size: NM 140 / Size 22

• Point Type: RG – Normal round point with small ball (also known as STU, STUB, S BALL, H SET, SET RT)

• Coating: GEBEDUR™ Titanium Nitride

• Shank Diameter: 2 mm

• Overall Length: 43.7 mm

• Length to Eye: 38.9 mm

• Needle Form: Straight with single groove and scarf

• Stitch Type: Class 300 – Double lockstitch

• Special Feature: Left-side point groove (for thread flow in multi-directional sewing)

• Recommended For: Technical textiles, woven fabrics, microfiber, coated fabrics

• Common Uses: Airbags, seat belts, tents, tarps, plastic foils, canvas covers, cushions, nets, embroidery, and button sewing

Why Choose Groz Beckert SAN 5 GEBEDUR Size 140 Needles?

When it comes to sewing the toughest materials in critical applications, Groz Beckert SAN™ 5 GEBEDUR needles deliver unparalleled strength, precision, and longevity. Designed for reliability under pressure, they reduce needle changes, prevent thread breakage, and ensure consistent high-quality stitching in any production setup.
