JUKI MO-6804S-0E4-30H 3 THREAD OVERLOCK INDUSTRIAL SEEWING MACHINE

Juki MO-6804S-0E4-30H – 3-Thread Overlock / Safety Stitch Machine (6800 Series)

The Juki MO-6804S-0E4-30H is a 1-needle, 3-thread overlock designed for light to medium-weight fabrics, delivering exceptional seam quality with advanced usability and durability. As part of the renowned MO-6800S Series, it combines high-speed performance with reduced noise, vibration, and maintenance requirements.

Capable of reaching 7,000 stitches per minute, this model produces soft, well-tensioned seams that flexibly adapt to different material elasticities. Its optimised thread take-up system ensures beautiful, professional finishes, even at maximum speed.

The MO-6804S offers a wider, brighter needle entry for improved visibility and smoother material handling, while its balanced design reduces operator fatigue during long production runs.

Key Features

• High-Speed Output – Up to 7,000 sti/min for maximum productivity.

• Exceptional Seam Quality – Needle and looper thread take-up systems produce soft, balanced stitches.

• Reduced Noise & Vibration – Enhances operator comfort and sewing stability.

• Front-Accessible Adjustments – Differential feed micro-adjustment, feed ratio, and feed dog height accessible from the front with a screwdriver.

• Wide Material Range – Handles light to medium fabrics with ease.

• Automatic Lubrication – Reliable oiling system for long-term performance.

• Operator-Friendly Design – Brighter needle entry for better visibility.

• Durable Build – Optimally balanced for stability and longevity.

Technical Specification

• Model: Juki MO-6804S-0E4-30H

• Series: MO-6800S

• Material Range: Light to medium-weight fabrics

• Needles / Threads: 1 needle / 3 threads

• Overedging Width: 1.5mm, 4.0mm

• Stitch Length: 0.6–3.8mm (max 4.5mm)

• Differential Feed Ratio: Gathering 1:2 (max 1:4) / Stretching 1:0.7 (max 1:0.6)

• Needle Bar Stroke: 24.5mm (60H: 27.0mm)

• Presser Foot Lift: 7mm

• Max Speed: 7,000 sti/min

• Needle System: DCx27 (#11 standard)

• Max Presser Foot Pressure: 63.7N (6.5kgf)

• Stitch Adjusting Method: Push-button

• Differential Feed Adjusting Method: Lever with micro-adjustment

• Weight: 27kg (head only)

• Lubrication: Automatic

• Lubricating Oil: JUKI Machine Oil 18 (ISO VG18)

• Extra Features: Needle cooler, needle thread heat remover (standard), micro-lifter (optional)
