JUKI MO-6704DA-0E4-307 – 3-THREAD OVERLOCK MACHINE

Juki MO-6704DA-0E4-307 is a semi-dry head, 1-needle, 3-thread overlock machine designed for light to medium-weight materials. Featuring JUKI’s advanced dry-head technology, it eliminates oil splashes in critical areas, ensuring professional, stain-free finishes.

With a maximum sewing speed of 7,000 stitches per minute, this high-speed overlock boosts productivity while maintaining exceptional seam quality. Its lubrication-free needle bar and upper looper mechanisms improve durability and reduce maintenance requirements.

Key Features

• Semi-Dry Head Technology – Prevents oil contamination on fabrics, eliminating stains and improving final product quality.

• High-Speed Output – Achieves up to 7,000 sti/min for fast, efficient production.

• Lubrication-Free Needle & Upper Looper Mechanism – Special surface treatments and grease-fed design enhance lifespan.

• Easy Maintenance – Two grease filler openings for quick servicing.

• Micro-Lifter Function – Reduces drag for smoother feeding on delicate materials.

• Smooth Differential Feed – Lever-operated with micro-adjustment for precise gathering or stretching.

• Wide Overedging – 4.0mm overedging width for durable and neat seams.

Subclass Specification

• Model: Juki MO-6704DA-0E4-307

• Material Range: Light to medium fabrics

• Needles / Threads: 1 needle / 3 threads

• Overedging Width: 4.0mm

• Stitch Length: 0.8–4mm

• Differential Feed Ratio: Gathering 1:2 (Max 1:4) / Stretching 1:0.7 (Max 1:0.6)

• Needle System: DCx27 #11

• Needle Bar Stroke: 24.5mm

• Presser Foot Lift: 7mm

• Max Speed: 7,000 sti/min

• Lubrication: Automatic (no lubrication required for needle bar & upper looper)

• Weight: 28kg (head only)
