JUKI PLC-2760-7 Twin Needle Direct-Drive Post-Bed UBT Industrial Sewing Machine

Juki PLC-2760-7 (8mm Gauge Set)

Discover the precision and power of the Juki PLC-2760-7, a 2-Needle Post-bed Lockstitch Machine equipped with a Vertical-axis Large Hook and automatic thread trimmer, tailored for heavy-weight material applications like car seats, sofas, and sports equipment.

Key Features:

• Enhanced Workability: Benefit from extended reach between the machine arm and needle, optimizing maneuverability.

• Versatile Stitching: Easily adjust stitch length across various settings with the standard 2-pitch dial, accommodating diverse sewing requirements.

• Noise Reduction: Engineered with resin components at key vibration points and a bevel gear for quieter operation.

• High-Torque Direct-Drive Motor: Ensures robust performance, delivering superior penetration through multi-layered materials.

• Stitch Precision: Integrated walking-foot and presser-foot alternating vertical movement mechanism prevents irregular stitches, maintaining consistency.

• Adjustable Feed Mechanism: Fine-tune the vertical movement ratio between walking foot and presser foot to 9mm, effortlessly controlled via a large dial.

• Enhanced Presser Bar Lift: Achieve a 20mm presser foot lift with the automatic lever, facilitating seamless handling of thick materials like leather and sponges.

• Customizable Feed Cam Eccentricity: Optimize feed performance tailored to specific materials and threads, eliminating the need for additional machine models.

• Dual Tension System: Seamlessly sew with low-count threads under higher tension, supported by the dual-tension thread tension system.

• Multi-functional Controls: Includes a 6-string switch for easy adjustment between single and double stitching modes, ideal for thicker materials.

• Efficient Thread Management: New bobbin thread spool device eliminates manual thread rolling, enhancing operational efficiency.

Technical Specifications:

• Model Name: Juki PLC-2760-7 (8mm Gauge Set)
• Type: 2-needle with automatic thread trimmer (Direct-drive)
• Max. Sewing Speed: 2,500 stitches per minute*
• Needle: 135×17
• Thread Compatibility: TEX 50~167
• Max. Stitch Length: 12mm (forward / backward)
• Stitch Adjusting Method: 2-pitch dial
• Thread Take-up: Link type
• Automatic Reverse Feed Function: Pneumatic type
• Needle Bar Stroke: 40mm
• Hook: Vertical-axis 2.0-fold capacity hook (latch type)
• Presser Foot Lift: By hand: 10mm, Auto: 20mm
• Alternating Vertical Movement: 1~9mm, adjustable via dial
• DL Device: Provided as standard
• Safety Mechanism: Provided as standard
• Bobbin Thread Winder: Built into the machine arm
• Bottom-feed Micro-adjustment Mechanism: Provided as standard
• Lubrication: Automatic (Tank system)
• Distance from Needle to Machine Arm: 347mm
• Post Height: 170mm
• Knee-lifter: -
• Auto-lifter: Option
• Weight of the Machine Head: 84kg
• Power Requirement / Consumption: Single-phase 100~120V / 200~240V, 3-phase 200~240V / 193VA (with automatic thread trimmer)
• Air Consumption: 0.1dm³/min (ANR)
