Schmetz 16X231 SERV 7 Size 90 Industrial Sewing Machine Needles – Pack of 10

Compatible with: DBX1 SERV 7, 16X231 SERV 7, 287 WH SERV 7, 1738(A) SERV 7 (CANU 14:25 17)

The Schmetz 16X231 SERV 7 Size 90 industrial sewing needles are built for superior stability and seam quality, especially when sewing elastic or stretch fabrics. The unique SERV 7 design features a reinforced blade for extra strength and a hump scarf that forms a larger thread loop, making it easier for the hook to catch the thread and reduce skipped stitches.

With 15–20% added blade reinforcement, these needles are less likely to bend or break under heavy use. They also help minimise stitch holes while improving fabric displacement, making them a trusted choice for professional sewing applications.

Key Features:

• Reinforced SERV 7 Design – 15–20% stronger blade for maximum stability.

• Hump Scarf – Enlarges thread loop for more reliable stitch formation.

• Skip-Stitch Prevention – Designed specifically for sewing elastic and stretch fabrics.

• Chrome Coating – Extends durability and reduces wear.

• Industrial Lockstitch Compatibility – Suitable for multiple needle systems.

Needle Specifications:

• Needle System: DBX1 SERV 7 / 16X231 SERV 7 / 287 WH SERV 7 / 1738(A) SERV 7 (CANU 14:25 17)

• Needle Size: Size 90 (NM 90 / Size 14)

• Point Style: Standard (Normal round point)

• Special Variant: Reinforced blade & hump scarf for fewer skipped stitches

• Shank Diameter: 1.62 mm

• Overall Length: 37.5 mm

• Length to Eye: 33.9 mm

• Shank: Round (no flattening)

• Blade Shape: Straight

• Grooves: Single groove

• Coating: Chrome

• Stitch Type: Lockstitch

Recommended Applications:

Perfect for medium to heavy elastic, woven, and stretch fabrics. Ideal for sewing uniforms, sportswear, and durable garments while preventing skipped stitches and ensuring long-lasting seam strength.
