Juki DNU-1541/X55268 Needle Feed Lockstitch for Thick Thread
JUKI DNU -1541/X55268
1-needle, Bottom and Variable Top-feed, Lockstitch Machine
Sewing capabilities have been dramatically improved fromthe standard DNU model. The feed and responsiveness to the material has been further improved. The force at which the machine is capable to penetrate material has also been increased. These improvements mean the sewing machine is able to sew a broad range of materials from genuine leather materials to lining materials.
High-speed performance increases productivity.
The machine delivers increased productivity at sewingspeeds as high as 2,500sti/min (DNU-1541, -1541S) or 3,000sti/min (DNU-1541-7).
When the thread is caught in the hook or any other sewing trouble occurs, the safety mechanism will automatically operate to prevent the machine from being damaged.
The vertical stroke of the walking foot and presser foot can be easily set and changed.
The vertical stroke of the presser foot and walking foot (amount of alternating vertical movement) can be easily changed with the large dial mounted on the top of the machine head. The sewing speed is automatically regulated based on the vertical stroke setting. This ensures ideal sewing conditions at all times.
Thread trimming without fail.
Consisting only of a moving knife and counter knife, the simple and well-balanced thread trimming mechanism is capable of cutting thick thread up to without fail.
A helpful automatic reverse feed function is provided as standard.
With just a light press on the one-touch type reverse feed button, reverse feed stitching is actuated.
Furthermore, if a suspended ruler is attached on the machine or a 3-dimensional sewing product is sewn, the button can be shifted upward to prevent interruption.
The area around the needle entry is designed to be easilyobserved.
Since the needle thread tension-release solenoid is fitted on the rear face of the machine head, the area around the needle entry and one-touch type reverse feed button is easily viewable.
This substantially contributes to improved operability.
- Model name:
- Centralized oil wick lubrication (hook: by an olier)
- Max. sewing speed:
- Max. stitch length:
- 9mm (Normal/Reverse feed)
- 136x17 Nm160 (Nm125~ Nm190)
- Needle Bar Stroke:
