JUKI LZ-2290CS-7 Semi-Digital Zigzag WB/AK155 Industrial Sewing Machine
CONTACT US FOR A QUOTE
- SKU:
- JUKILZ2290CS7WBAK155
- Condition:
- New
Juki LZ-2290CS-7 Semi-Dry Head Digital Zigzag Stitch Sewing System. This cutting-edge machine epitomizes innovation in the sewing industry, integrating digital precision with user-friendly functionality.
Experience Versatility: The LZ-2290CS-7 comes equipped with 11 types and 20 patterns of basic stitch shapes, including essential options like zigzag and T stitching. Its new operation panel allows seamless selection of stitching patterns, enhancing operational efficiency across various applications. Ideal for producing intricate designs such as tailored men's garments and pattern stitching for women's apparel, it supports custom pattern creation for expanded versatility.
Smart Connectivity and Data Management: Integrating IoT technology, this machine facilitates two-way communication for parameter adjustment via commercial Android terminals. Manage and monitor sewing machines in a production line effortlessly, ensuring uniform settings and quality control. The standardized control panel features USB ports for easy data management and updates, while the JUKI Smart APP provides comprehensive data analysis tools for production optimization.
Efficient and Eco-Friendly Design: Designed for energy efficiency, the LZ-2290CS-7 incorporates automatic OFF and sleep mode functions to conserve power during idle periods. Its semi-dry head system reduces oil stains on fabrics, promoting cleaner sewing environments. An integrated LED light under the arm enhances visibility, adjustable to reduce operator fatigue, while a strategically placed cooling fan minimizes heat from the hook unit.
Enhanced Operational Features: Operate with precision using the triple hand switch, supporting functions like touch-back, mirror, and multi-layered portion corrections. Standard features include a back lever for reverse-feed stitching and a hook timing adjustment mode, ensuring seamless handling of delicate sewing tasks.
Technical Specifications:
- Model: Juki LZ-2290CS-7 (Automatic thread trimmer included)
- Stitch System: Digital type
- Max. Sewing Speed: 5,000 sti/min (4,000 sti/min at shipment)
- Max. Zigzag Width: Standard 8 mm (up to 10 mm with gauge change)
- Needle Throwing Mechanism: Motor control
- Feed Mechanism: Motor control (horizontal), Mechanical type (vertical)
- Max. Feed Amount: 5.0mm (2.5 mm at shipment)
- Thread Take-up Lever: Rotary type
- Presser System: Spring type with multiple lift options
- Operation Panel: Color touch panel with NFC function
- Memory Capacity: 200 custom patterns, up to 500 stitches per pattern
- Machine Head Drive: Compact AC servomotor (400 W)
- Oiling: Semi-dry system (Grease lubricated frame, hook oil supplied)
- Power Consumption: 530VA
- Product Weight: 49.0 kg
