JUKI LZH-1290-7 Zigzag Industrial Sewing Machine

Juki LZH-1290U-7 1-Needle Lockstitch Zigzag Sewing Machine with Large Hook and Automatic Thread Trimmer

Ideal for the precision sewing of sports shoes and leather products, the Juki LZH-1290U-7 excels in delivering uniform, high-speed zigzag stitches. Featuring an extended zigzag width, enhanced presser foot lift, and a new horizontal-axis double-capacity hook, this machine is tailored to handle heavy materials with ease.

Key Features:

• Extended Zigzag Width: Perfect for sports shoes and leather sewing, easily adjust the zigzag width using the front-mounted dial.

• Higher Presser Foot Lift: Ensures smooth sewing of thick materials with a presser foot lift of up to 13mm.

• Automatic Thread Trimmer: The machine's innovative thread trimmer cuts threads effortlessly at both ends of the zigzag stroke, eliminating the need for adjustments even with thread count changes.

• Consistent High-Speed Performance: Equipped with a triangular cam that maintains uniform thread tension throughout zigzag stitching, preventing needle sway and ensuring precise stitching at all times.

Technical Specifications:

• Model: Juki LZH-1290U-7
• Type: Automatic thread trimmer included
• Max. Sewing Speed: 2,000 stitches per minute
• Max. Stitch Length: 6 mm (normal/reverse feed)
• Max. Zigzag Width: 8 mm (adjustable up to 10 mm)
• Zigzag Width Adjustment: Dial-operated
• Needle Bar Stroke: 35 mm
• Presser Foot Lift: Knee lifter: 13 mm, Hand lifter: 6 mm
• Thread Take-up: Link type
• Hook: Horizontal-axis full-rotary double-capacity hook
• Needle: SY1906 Nm90~110 (standard Nm110)
• Thread Compatibility: #50~#8, B33~B92, Nm=120/3~30/3
• Lubrication: Automatic oiler (hook), JUKI New Defrix Oil No.1 (equivalent to ISO VG7)
• Distance from Needle to Machine Arm: 295 mm
• Bed Size: 477 mm × 178 mm
• Machine Head Weight: 39 kg
• Automatic Reverse Feed Function: Included as standard
