Juki DDL-8700H Lockstitch (Heavy Duty)

*THIS IS A HEAVY DUTY JUKI DDL-8700H SET UP SPECIFICALLY FOR HEAVY MATERIALS*

High-speed, 1-needle, lockstitch machine.

JUKI's newly designed unique lockstitch machine, which perfectly matches clothing plants for creating the 21st century fashion.

Newly designed machine head that was developed in pursuit of beauty

The optimum-balance and highly rigid machine head were created using the latest 3D-CAD design technology. Thanks to its low vibration and low noise feature, the machine head provides the operator with a comfortable work environment. In addition, the distance from the machine arm to the needle on the front of the machine head is sufficiently wide to allow easy handling of the sewing material. The machine inherits the desirable features, such as high- speed stitching performance 5,500sti/min, extreme stitching performance, ease of operation, and reliability, from the highly evaluated previous JUKI lockstitch machines.

Maintainability was improved
Enhanced maintainability is ensured by the improved machine head, such as incorporation of an eccentric pin that is used to adjust the feed dog. In addition, the machine is provided with a mounting seat for attachment to improve workability whilea replacing the attachment and increasing the durability of the machine bed surface.

Sewing mechanism that demonstrates outstanding responsiveness to materials to be sewn
By thoroughly investigating and modifying the sewing mechanisms in order to achieve low-tension sewing, the machine flexibly responds to various kinds of materials and produces beautiful seams of consistent quality.

The machine has easy-to-operate functions to achieve improved operability
By providing a presser foot with a higher lift(13mm), a light- touch stitch dial, a throat plate with marker grooves that can be used as guide for seam allowance, and other easy-to-operate functions, the burden on the operator is lightened, and productivity is further increased.

Complete with a unit stand, with the added benefit of wheels (to help with moving if required)

Features:
Speed Adjustment

Silent Running (Servo/Energy Motor)

Needle Positioning (Optional Output)

Lockstitch

Straight Stitch

Working Pressure Adjustment

Adjustable Stitch Length

Reverse Lever (Back Tack)

Hand Lever

Knee Lever

External Bobbin Winder

Self Oiling (Oil Reservoir)



Specification:

Weight (45kg)

Max Sewing Speed (5500 spm)

Maximum Stitch Length (5mm)

Presser Foot Lift (5.5mm by hand/13mm by knee)

Needle Bar Stroke (30.7mm)
Needle System (DBx1/16x231)

Motor Power (550w)
Single Phase (240v)

Accessories Included:

Needles

Bobbins

Manual

Oil
